R154.34 - SNR


NTN-SNR's expertise is exemplified in the WHEEL BEARING KITS range:

  • An increasingly extensive range to meet all the needs of the market.
  • Kits comprising both bearings and the associated components for a complete and reliable replacement.
  • Original quality parts for guaranteed safety.


Technical datasheet

KitThis kit contains the following reference(s)- GB.12320.R05- CIR- ECR- ECR- ECR (x2)- VIS
PLEASE LOGIN to add products to your basket
Contact us
External diameter 172 mm
Internal diameter n°140 mm
Width 137 mm
Weight0,755 kg
Bearing typeGB




BrandModelGenerationDatePositionLocationSEATToledoToledo série 102/1994 => 08/1998Left / RightFRONTVOLKSWAGENCorradoCorrado07/1991 => 06/1995Left / RightFRONTVOLKSWAGENGolfGolf III10/1991 => 03/1999Left / RightFRONTVOLKSWAGENPassatPassat III01/1992 => 09/1993Left / RightFRONTVOLKSWAGENPassatPassat IV09/1993 => 04/1997Left / RightFRONTVOLKSWAGENVentoVento12/1991 => 11/1997Left / RightFRONT
