Scheda tecnica
Specifica
CARATTTERISTICHE TECNICHE | |
|---|---|
| d1 | 135 mm |
| d | 140 mm |
| B1 | 104 mm |
| B4 | 109 mm |
| G | M150X2 |
| IG | 15 mm |
| Designation of the associated nut | KM30 |
| Designation of the associated blocking device | MB26 |
| Designation of the nut | KM26 |
| Associated bearing | 23228 |
| Designation of the associated hydraulic nut | HMV30 EBF |
| Tipo di alesaggio | Tapered 1:12 |
| Peso | 1,76 kg |
| Marchio | SNR |
