CARACTERÍSTICAS TÉCNICAS | |
---|---|
Marca | SNR |
d3 - Safety washer bore diameter | 120 mm |
d4 - Tooth root diameter | 138 mm |
d5 - Outer diameter of the safety washer | 164 mm |
B7 - Security washer thickness | 2 mm |
M - Distance between inner tab and bore diameter | 115 mm |
f - Width of outer teeth | 12 mm |
f1 - Inner tab width | 14 mm |
Peso | 0,173 kg |
CARACTERÍSTICAS TÉCNICAS | |
---|---|
Designation of the associated nut | KM24 |
