UKF207HN - SNR

UKF207HN

Grey cast housing, radial insert ball bearing with adapter sleeve,seal with slinger

Self aligning bearing units with different fixing options and housings made of cast, stainless steel or plastic.

Scarica

Scheda tecnica

KitIl kit contiene le seguenti referenze - UK207G2H - F207N
Accedi per aggiungere i prodotti al carrello
Contact us
Specifica

PRODUCT DIMENSIONS

Housing height (A) 34 mm
Housing foot height / flange height (A1) 15 mm
Total height (Housing + Insert) from mouting surface (A2) 41,5 mm
Width of IR (B) 27 mm
Overall width IR incl. eccent. locking collar/adapt. sleeve(B1) 43 mm
Shaft dia (d) 30 mm
Outer dia of eccent. Lock. collar / nut of adapter sleeve (d1) 52 mm
Distance mounting surface - bearing center (e) 19 mm
Grease fitting (G) M6x1
Mounting hole distance (J) 92 mm
Housing width / dia (L) 117 mm
Mounting hole dimension (N) 14 mm
Distance nut - middle of bearing raceway 22,5 mm
Brand SNR
Product classification image

PRODUCT PERFORMANCE

Dynamic load rating (C) 25,7 kN
Static load rating (C0) 15,2 kN
Operating temperature min. -20 °C
Operating temperature max. 100 °C

OTHER FEATURES

Mass 1,55 kg
Adapter sleeve reference H2307
